_ 14
Name of each part (Rear camera)
06
Name Functional description
①
Adhering surface Surface to attach the rear camera to a rear window
②
Security LED Blue LED for indicating operation state and security
③
Camera lens Rear camera lens
④
Terminal Micro USB 5-pin port to connect the body
⑤
Screen reversal switch Horizontal reversal switch for rear-view screen (N: Normal / M: Horizontal reversal)
1
2
5
3
4
