19
Overload Protection: Fuse 1: F 400mA/690V
Fuse 2: F 10A/690V
Max. Input Current: 10A (For inputs > 2A : measurement duration
< 10 secs, interval > 1
5 minutes)
Frequency Range: 40Hz ~ 400Hz
Response:
Average, calibrated in rms of sine wave
Max. Voltage Drop: 400mV
Note: The 10A range is specified from 20% to 100% of range.
Frequency
Range Resolution Accuracy
10Hz 0.01Hz ± (1.0% + 3)
100Hz 0.1Hz
± (0.8% + 3)
1kHz 0.001kHz
10kHz 0.01kHz
100kHz 0.1kHz
Input Voltage: 1Vrms -20Vrms
Duty Cycle
Range Resolution Accuracy
5% ~ 99% 0.1%
1 Hz ~ 10kHz: ± (2% + 5)
> 10kHz: not specified
Input Voltage: 3Vp-p ~ 10Vp-p
Overload Protection: 600V DC/AC rms
Resistance
Range Resolution Accuracy
400ȍ 0.1ȍ ± (1.0% + 5)
4kȍ 0.001kȍ
± (1.0% + 3)
40kȍ 0.01kȍ
400kȍ 0.1kȍ
4Mȍ 0.001Mȍ
40Mȍ 0.01Mȍ ± (1.8% + 5)
Capacitance
Range Resolution Accuracy
40nF 0.01nF ± (4%+20)(REL)
400nF 0.1nF ± (3%+5)(REL)
4µF 0.001µF
± (4% + 5)
40µF 0.01µF
100µF 0.1µF ± (8% + 5)
For the ranges ) 400nF, use Relative mode (REL) to subtract the stray capacitance of the
test leads and the Meter.
For the range of 100µF, wait about 30 secs for the reading to settle.
