USASPEC BT45-HON3 - Installation Instruction B: Connecting behind the radio

7
8
Installation
Instruction B:
Connecting behind
the radio
Use the CAS-H3t and
CAS-H3x Cable. Do not
disconnect the two cables
Install the BT45 interface
module in an easily
accessible location.
Install the microphone
See Diagram C (p. 9) for
recommended locations.
Cable Connections
Refer to Diagram B (p. 8)
Remove radio from the
dash.
Pair the Bluetooth
Device (phone)
See p. 10 for instructions
Learn about audio streaming,
handsfree phone calls, and
AUX input on p. 11-13.
Make sure you have
completed all of the above
steps and made a couple of
test calls before putting
your car back together.
Diagram B: CAS H3T to Radio
18-pin male
CAS-H3x
Factory 14-pin
Radio Cable
14-pin female
14-pin male
CAS-H3t
TO RADIO
BT45 Interface Module
Radio
