PARTS LIST
MODEL 1557M
(SEE DIAGRAM, PAGE 18)
KEY PART # DESCRIPTION QTY.
1 69509 Firebox Weldment 1
2 25467G Cabinet Side (Left & Right) 2
3 88032 Flue Collar Gasket 1
4 40246 Flue Collar 1
5 23459G Cabinet Back 1
6 25466G Cabinet Top 1
7 40258 Rear Liner 1
8 40269 Front Liner 1
9 23398 Baffle 1
10 40256 Shaker Grate Frame 2
11 40257 Shaker Grate 2
12 40260 Shaker Handle 1
13 23800 Smoke Curtain 1
14 83445 1/4-20 x 1-1/4 Carriage Bolt 2
15 23787 Smoke Curtain Clip 2
16 83250 1/4-20 Kep Nut 2
17 68218 Ash Door Assembly (Includes Door and Gasket) 1
18 23859B Draft Cap (Painted) 1
19 891098 Ash Door Handle 1
20 89574 Spring Handle 1
21 ***** Handle Bushing (Included with Handle) 1
22 23445 Door Latch 1
23 83461 Handle Washer 1
24 83178 3/8-16 Jamb Nut 1
25 22662 Feed Door Hinge Bracket 1
26 68217 Feed Door Assembly (Includes Door and Gasket) 1
- 69511 Damper Control Box Assembly (Includes the Following) 27 - 34
27 69396 Control Plate Assembly 1
28 25200 Slide Damper - Secondary Air Control 1
29 89041 Spring 1
30 83278 #10 Flat Washer 3
. 31 83244 10-24 Kep Nut 2
32 25197G Control Box Cover (Painted) 1
33 25199G Pull Handle (Painted) 1
34 89943 Knob, Slide Damper 1
35 891097 Feed Door Handle Assembly 1
36 89574 Spring Handle 1
37 89066 Firebrick (4-1/2W x 9L x 1-1/4H) 12
38 68228 Ash Pan Weldment 1
39 22761 Flue Collar Ring 1
40 22762 Forced Draft Ring 1
41 68234 Blower Thermostat Bracket 1
42 80314 Thermodisc 60T12 1
43 22140 Relay Box Bracket 1
44 80131 Junction Box (4 x 4) 1
45 80231 Junction Box Cover 1
46 89319 Blower Gasket 2
47 80230 Blower Assembly 2
N/S 68231 Fan Control Cord Assembly 3
N/S = NOT SHOWN
FOR MODEL: 1557M
