UVP GelDoc-It2 - 4 System Design; Components

System design
9
81-0220-01 Rev R
4 System design
4.1 Components
Refer to the packing slip and pictured components for specific parts and components
included with the system.
Note: The delivered system may look slightly different (without cover, only with different
camera bracket).
GelDoc-It
®2
& ChemiDoc-It
®2
Imagers
Camera and Lens Kit
(actual configuration may
be different than shown in
the photo)
Lighting and UV
Timer Switches
Epi Overhead
White Light
Four Position
Emission Filter
Selector
UV Safety
Interlock Switch
UV-Safe Gel
Viewer
Window
Roll-Out
Transilluminator
LED White Light
Plate (Optional)
Access port
for optional
BioLite™
MultiSpectral
Light Source
