Continuous level measuring system
NB 3000
Technical information / Instruction manual
page
Technical data
Mechanical data
Ingress protection IP66, Type 4
Process connection Threads: R 1½" EN 10226 tapered,
NPT 1½" or 3" ANSI B1.20.1 tapered
Flanges: DN100 PN16 EN 1092-1 (unit ts to this ange)
2" or 3" or 4" 150lbs ANSI B16.5 (unit ts to this ange)
Colour Housing, Flange RAL 5010 (gentian blue)
Lid RAL 9006 (aluminium silver)
Material See detail specications on page 4 - 6
Measuring range Rope version max. 30 m (100 ft)
Tape version max. 50 m (164 ft)
Measuring speed Sensor weight speed in average:
Standard version: ca. 0.25 m/s (0.8 ft/sec)
Version with brushless motor: ca. 0.33 m/s (1.0 ft/sec)
Sound level max. 50 dBA
Weight Rope version with ange: ca. 11 kg (24.2 lbs)
with thread: ca. 12 kg (26.4 lbs)
Tape version with ange: ca. 12 kg (26.4 lbs)
with thread: ca. 13 kg (28.6 lbs)
Deviation of vertical
mounting
max. 2°
max. 1° for tape version with extended socket pipe (see page 4)
Compressed air connector
(Option)
Quick coupling incl. opposite part, for hose diameter 9 mm (0.35“), female at housing
Max. operating pressure 0.2 bar (2.9 psi)
Memory Non-volatile (no backup battery required) > 10 years data retention
Connection terminals 0.14 .. 2.5 mm
2
(AWG 26 .. 14)
Cable entry According to selection:
Screwed cable gland: 2x M20 x 1.5 and 1x M25 x 1.5 Blindplug: 2x M20 x 1.5 or
Conduit ANSI B1.20.1: 1x NPT ¾" and 2x NPT ½"
Blindplug: 2x NPT ½"
Clamping range (diameter) of the factory provided cable glands:
M20 x 1.5: 6 .. 12 mm (0.24 .. 0.47")
M25 x 1.5: 8 .. 17 mm (0.31 .. 0.67")
Extension cables for
Probus DP/ Modbus
Use common recommended cables
Isolation Power supply to all other outputs/ inputs: AC version 2,210 Vrms
DC version: 1,000 VDC
Relay to relay: 2,210 Vrms
Protection class I
Overvoltage category II
Pollution degree 2 (inside housing)
Nivobob
®
1
2
3
4
5
6
7
8
9
10
11
12
NB 3000 b
gi020116
8
