V-Sol V2802W User Manual

G/EPON 1GE+1FE+WiFi+CATV ONU Introduction V1.1
4 Access the world
Wireless
WiFi
On
WiFi turned on.
Off
Device is power off or WiFi turned off.
Blink
WiFi data transmission.
CATV(for
V2802WT)
CATV
On
1550nm wavelength power of input is in normal range.
Off
1550nm wavelength power of input is too low or no
input.
Blink
1550nm wavelength power of input is too high.
Table 3 Panel lights on
1.6 Interface description
Port Type
Function
PON
V2802W: SC/UPC type, single mode optical fiber cable
V2802WT: SC/APC type, single mode optical fiber cable with WDM
GE、FE
Connect device with ethernet port by RJ-45 cat5 cable.
RST
Press down reset button and keep1-5seconds to make the device
restart and recover from the factory default settings.
DC12V
Connect with power adapter.
CATV★
RF connector.
Power On/OFF
Power turn on/off.
Table 4 Interface description
Note:
1. With ★ tags, it is only for V2802WT.
1.7 Software Parameters
Parameter
Name
Software Parameters
EPON/GPON
mode
Dual Mode , Can access EPON/GPON OLTs(HUAWEI、ZTE、FiberHome,
etc)
Software
mode
Bridging and Routing Mode
Basic
Support MPCP discover&register
Support authentication Mac/Loid/Mac+Loid
Support Triple Churning
Support DBA bandwidth
Support auto-detecting, auto-configuration, and auto firmware upgrade
Support authentication SN/Psw/Loid/Loid+Psw
Alarm
Support Dying Gasp
Support Port Loop Detect
Support Eth Port Los
LAN
Support Loop Detection
Support Storm Control
