VABCHES D3M545HS05 - D3 M545 HS05-梳妆台-说明书-2023-03-16-04; 图纸和视图; 模型

Ø15X9.5mm
CAM LOCK
spare:2
X16
Ø6.5X35mm
CAM BOLT
spare:2
X16
Ø8X30mm
WOODEN DOWEL
spare:2
X20
Ø6X30mm
WOODEN DOWEL
spare:2
X16
Ø6.3X50mm
SCREW
spare:2
X20
SCREW
spare:3
X32
Ø4X40mm
SCREW
spare:3
X30
M6X20mm
BOLT
spare:1
X6
Ø4X14mm
SCREW
spare:1
X2
M4X15mm
X4
Ø3.5X14mm
X2
BOLT
spare:1
HANDLE
5-32
Part List
1 2 3 4
5 6 7 8
9 10 11
HEX KEY
4X65mm
13
X1
102*8*16mm
X1
X4
PLUG BOARD
X1 X30
HAIR DRYER RACK ANGLE BRACKET PERFECT
apare:3
20X20X15mm
LEFT CABINET MEMBER
X2
300mm
12CL
12''
X2 X2
RIGHT CABINET MEMBER
X2
300mm
12CR
12''
12DL 12DR
LEFT DRAWER RUNNER
RIGHT DRAWER RUNNER
300mm
12''
300mm
12''
14 15 16 17
Ø21mm
