Part List
6-32
Cam Lock
Fastening
System
Insert the cam bolt into the
hole first, then insert the
cam lock and lock it.
1
3
2
4
The opening must point toward the
edge of the board
LIGHT BULB
X1 set
ANTI-TIPPING HARDWARE
X1 set
18 19
GROMMET
X1
20
Ø35mm
