UNPACKING & CHECKING CARTON
CONTENTS
Remove all contents from the box.
Remove the power head and take out any
contents inside the collection tank.
Check each item against the carton
contents list.
A
B
C
K
M
F
H
D
E
G
J
I
L
Carton Contents List
Key Description....................Qty.
A Vacuum Assembly ...................1
B Extension Wands.......................3
C Hose ........................................1
D Cartridge Filter............................1
E Filter Retainer............................1
F Foam Wet Filter.........................1
G Floor Brush / Squeegee Nozzle..1
H Crevice Tool .............................1
I Blower Adapter..........................1
J Blower Tube...............................1
K 4 Screws (Bag)..........................1
L Caster Foot Assembly............4
M Operator’s Manual.....................1
Handle
Blower Port
Collection
Tank Lid
Accessory Storage
On/Off Switch
Caster Foot
Collection
Tank
Power Head
Caster
Vacuum Port
Blower Release
Button
Latch
Blower Handle
Hose Storage / Cord Storage
NOTE: The hose and accessories for this
vacuum are 1.25” (3.2 cm) diameter.
