Parts Information
Part # Part Name Qty
1 979333 Seal Bar Assembly, Front 1
2 979332 Seal Bar Assembly, Side 2
3 Chamber Assembly 1
4 979380 Piston Assembly 8
5 979229 Hinge, Left 1
6 979358-8 Upper Anchor Bolt 2
7 979346 Gas Shock 2
8 Split Washer 10
9 979357 Lower Anchor Bolt 1
10 979156 Solenoid Valve Hose 140 In
11 Supporting Rod of Hinge 2
12 M10x1 Solenoid Valve Pipe Connections 9
13 O Ring 9
14 Airbag Tube Connector 1
15 Dispenser 1
16 Gas Spring Bracket 1
17 Mounting foot 1
18 977482 Microswitch 1
19 979399 Seat, microswitch 1
20 979357 Lower Anchor Bolt 1
21 979553 Hinge Pin 2
22 979228 Hinge, Right 1
CHAMBER ASSEMBLY
18
VP330 Chamber Vacuum Sealer | User Guide
ARY, Inc. | 11880 College Blvd Suite 550 Overland Park, KS 66210 | www.VacMasterFresh.com | 800-821-7849
