Parts Information
Part # Part Name Qty
1 Bolt 4
2 Upper Pressing Plate 2
3 979331 Domed Lid 1
4 979428 Lid Gasket (Made to t) 1
979263 Lid Gasket 10 ft
5 Lower Pressing Plate 2
6 979228 Hinge, Right 1
7 979299 Top Bar, Side (Side seat for rubber strip) 2
8 979419 Seal Pad, Side 2
9 979298 Top Bar, Front (Front seat for rubber strip) 1
10 979422 Seal Pad, Front 1
11 979229 Hinge, Left 1
DOME ASSEMBLY
17
VP330 Chamber Vacuum Sealer | User Guide
