18
Parts Information
Part # Part Name Qty
1 979805 Hexagon Socket Head Cap Screw 4
2 979800 Upper washer, Lid 2
3 979671 Lid 1
4 979801 Lower washer, Lid 2
5 979683 Lid Gasket 1
6 979825 Top Bar, Tape 1 roll
7 979684 Top Bar, Side 2
8 979696 Seal Pad, Side 2
9 979685 Top Bar, Front 1
10 979686 Seal Pad, Front 1
11 Sticker 2
LID ASSEMBLY
ARY, Inc. | 11880 College Blvd Suite 550 Overland Park, KS 66210 | www.VacMasterFresh.com | 800-821-7849
VP680 Chamber Vacuum Sealer | User Guide
