technical data vacon • 19
24-hour support: +358-(0)40-8371 150 • Email: vacon@vacon.com
4
4.3 Technical information
Input voltage U
in
465...800Vdc ( 380-500 Vac)
640...1100Vdc ( 525-690 Vac)
The waviness of the inverter supply voltage, which
is formed in rectification of the electric network's
alternating voltage in basic frequency, must be less
than 50V peak-to-peak.
Input current I
in
(sqrt3 × U
mot
× I
mot
× cosϕ) / ( U
in
× 0,98)
DC bank capacitance
FI9_5 : 4950µF; FI9_6 : 3733µF
FI10_5: 9900µF; FI10_6: 7467µF
FI12_5: 19800µF; FI12_6: 14933µF
FI13_5: 29700µF; FI13_6: 22400µF
Supply
connection
Starting delay 5 s (FI9 and greater)
Output voltage 3 ~ 0 – U
in
/ 1,4
Continuous output
current
I
H
: Ambient temperature max. +40°C,
overload 1.5 × I
H
(1 min./10 min.)
I
L
: Ambient temperature max. +40°C,
overload 1.1 × I
L
(1 min./10 min.)
Starting torque I
S
for two seconds, torque motor dependent
Peak current I
S
for 2 s every 20 s
Output frequency 0…320 Hz ; 7200 Hz (Special)
Motor
connection
Frequency resolution Application dependent
Control method Frequency control U/f
Open Loop Sensorless Vector Control
Closed Loop Frequency Control
Closed Loop Vector Control
Switching frequency
(see parameter 2.6.9)
NXI_5:
NXI_6:
1…10 kHz; Factory default 3.6 kHz
1…6 kHz; Factory default 1.5 kHz
Frequency reference
Analogue input
Panel reference
Resolution 0.1% (10-bit), accuracy ±1%
Resolution 0.01 Hz
Field weakening point 30…320 Hz
Acceleration time 0…3000 sec
Deceleration time 0…3000 sec
Control
characteristics
Braking torque DC brake: 30% * T
N
(without brake)
Ambient operating
temperature
–10°C (no frost)…+40°C
Storage temperature
–40°C…+70°C
Relative humidity 0 to 95% RH, non-condensing, non-corrosive,
no dripping water
Air quality:
- chemical vapours
- mechanical
particles
IEC 721-3-3, unit in operation, class 3C2
IEC 721-3-3, unit in operation, class 3S2
Ambient
conditions
Altitude 100% load capacity (no derating) up to 1,000 m
1-% derating for each 100m above 1000.; max.
2000m
