34 • vacon cabling and connections
Tel: +358-201-2121 • Fax: +358-201-212 205
6
Figure 6-2, FI9/10 basic wiring diagram with charging
DC
+
DC
-
COOLING FAN
B+
B-
UVW
NXP
CONTROL
FI 9/10
M
X9 X15X10 H1...H7
PE
EXTERNAL
SUPPLY
21 22 23
X15
CHARGING
RELAY
25 26
X9
CHARGING
FEEDBACK
24VDC
OEVA
