Vacon FI9 - Terminal Sizes for NXI_xxxx 5

44 • vacon cabling and connections
Tel: +358-201-2121 • Fax: +358-201-212 205
6
6.1.1.6 Terminal sizes, NXI_xxxx 5
Frame Type
I
L
[A]
DC supply terminal] Motor cable terminal
NXI_0168 5 170
NXI_0205 5 205
NXI_0261 5 261
NXI_0300 5
FI9
300
40
13
35
16
PE: M8 × 25
6 x 40
13
38
17
NXI_0385 5 385
NXI_0460 5 460
NXI_0520 5
FI10
520
40
13
50
16
PE: M8 × 25
6 x 40
13
38
17
NXI_0590 5 590
NXI_0650 5 650
NXI_0730 5 730
NXI_0820 5 820
NXI_0920 5 920
NXI_1030 5
FI12
1030
40
13
50
16
PE: M8 × 25
6 x 40
13
38
17
NXI_1150 5 1150
NXI_1300 5 1300
NXI_1450 5
FI13
1450
PE: M8 × 25
Table 6-5. Terminal sizes for Vacon NX_5
6.1.1.7 Inverter supply and motor cables, NXI_xxxx 6
