30 VADA FLOW BOSS HORIZONTAL MULTISTAGE PUMP VFB-HM110 INSTALLATION MANUAL
OPERATION
5. Open the outlet on discharge line and
open isolation valve on the discharge line
to 100%. This will assist with removal of
unwanted air
Note: without an VFB-APC or VFB-DSU the
pump will continue to operate until the power
is switched off.
Note: On initial start-up the pump will run until
the discharge line is primed.
6. Once all pipework has been filled on the
discharge side and tap/outlet side, turn off
the tap.
Note: The pump will run for a short period of
time until the system is again pressurised and
then stop.
7. The pump set up is now ready for use.
8. If no water is delivered, it may mean the
pump has failed to prime. The pressure
controller will indicate this by flashing red
for 1 minute, as the pump continues to turn
on, then off. After 1 minute, the VFB-APC
will have detected the loss of prime and will
go into a 24 hour lock out mode. To
manually reset the VFB-APC, you can
press the restart button.
Horizontal Multistage Pump and
Digital Water Switching Unit
For operating instructions, please refer to the
complete Digital Water Switching Manual.
Error
Pump on
Power on
Restart
1~240V 50 Hz
Max 1.5kW 10A
Max 65°C
IP65
Max 1MPa (10 bar)
AUTO PRESSURE CONTROL
VFB-APC
VFB-DSU
Installation
Manual
