A. 422mm
B. 162mm
C. 129mm
D. 180mm
E. 177mm
F. 207mm
Outlet port: 25mm FI
Suction port: 25mm FI
Weight: 9.7kg
PRODUCT DIMENSIONS VFB-HM110
A
B
Outlet port
D
E
F
C
Suction port
33
