TECHNICAL INFORMATION VFB-HM110
CONSTRUCTION
Pump casing X5 CrNi 1810 (AISI
304) stainless steel
Motor casing Die-cast aluminium
Impeller Fiberglass
Reinforced PPO
Diffuser Fibreglass
Reinforced PPO
Shaft X12 CrNiS 1809 (AISI
416) stainless steel
Mechanical seal Carbon graphite/
NBR/AISI 304 SS
Counterface Ceramic
Seal holder plate Fiberglass
Reinforced PPO
O-ring Nitrile Butadiene
Rubber 70
USAGE LIMITATIONS
Liquid type Clean water with no
suspended solids or
abrasive material
Max. liquid temp 50°C
Max. ambient temp 40°C
Min. ambient temp 0°C
Max. recommended
suction height
8m
Max operating
pressure
800kPa / 8 bar
MOTOR
IP rating IP55 (motor)
Speed of rotation 2850rpm (motor)
Insulation Class F (motor)
Enclosed, externally ventilated
Capacitor permanently activated
Thermal protection built into
the motor winding
Suitable for continuous use
POWER
Nominal power HP 0.94
kW 0.70
Absorbed power HP 1.27
kW 0.95
Voltage 1~230 – 240V 50Hz
Full load amps 4.3
µF 16
Q L/1’ 10 20 30 40 50
m3/h 0.6 1.2 1.8 2.4 3
Discharge
in meters
56.5 53 48.5 42 35.5
