VADA VFB-HM110 - Page 35

B
A
Power on
Pump on
Error
Restart
AUTO PRESSURE CONTROL
FLOW BOSS
240-50Hz
Max 1.5kW
Max 1MPa
8A
IP65
C
A. 174mm
B. 188mm
C. 147mm
PRODUCT DIMENSIONS VFB-APC
SPECIFICATIONS
Inlet 25mm MI
Outlet 25mm MI
Max operating
pressure
1000kPa / 10 bar
Min pump pressure 250kPa / 2.5 bar
Min – max water
temperature
1°C – 65°C
Min – max ambient
temperature
1°C – 40°C
Supply voltage 1~240V 50Hz
Cut-in pressure 150 – 300kPA /
1.5 – 3 bar
Max power 1.5kW
Max current 10A
IP rating IP65
TECHNICAL INFORMATION VFB-APC
35
