PRODUCT DIMENSIONS VFB-MSU25
A. 210mm
B. 148mm
SPECIFICATIONS
Pump inlet 25mm FI
Mains water in 25mm FI
Outlet 25mm FI
Max mains
pressure
1000kPa / 10 bar
Min pump pressure 350kPa
Max flow rate 100lpm
Max water temp 50°C
* Ensure proper protection against
freezing weather.
Certified to Watermark standard WMTS477.
Complies to AS/NZS 3500.1 when installed
by a licensed plumber
Note: According to AS/NZS 3500.1 maximum
allowable pressure in buildings is 500 KPa.
TECHNICAL INFORMATION VFB-MSU25
