6 VADA FLOW BOSS HORIZONTAL MULTISTAGE PUMP VFB-HM110 INSTALLATION MANUAL
• Pump inlet: 25mm MI
• Pump outlet: 25mm MI
• Max water temp: 65°C
• Minimum pump pressure: 250kPa / 2.5 bar
• Maximum operating pressure: 1000kPa / 10 bar
• You will need a flathead screwdriver if adjusting the cut-in pressure.
• Ensure your pump set up is equipped with two isolation valves. This allows for fuss free
troubleshooting the suction and discharge lines, should you need it.
KNOW YOUR PRODUCT VFB-APC
The Vada Flow Boss Auto Pressure Control VFB-APC gives you perfect control of household
pressure pumps, guaranteed. Designed with an LED light panel to signal the state of operation,
a built in pressure gauge to allow for adjustable cut-in pressure and a 24 hour reset function
for hassle free operation.
SPECIFICATIONS VFB-APC
HELPFUL HINTS
Power On indicator
Pump On indicator
Error indicator
Restart button
Three-wire cable
25mm MI Inlet
Cut-in pressure
adjustment point
25mm MI Outlet
