ProductionVIEW Precision Camera Controller
ProductionVIEW Precision Camera Controller Manual 341-770 Rev H Page 14 of 16
APPENDIX 2: COMMAND STRUCTURE DEFINITIONS
Command Parameters Description
AWB AWB On/Off(cr) Auto White Balance On/Off
BLC BLC On/Off(cr) Backlight Compensation On/Off
Camera Camera [9](cr) Select indicated camera (1-7)
ClearAll ClearAll(cr) Clear all presets
Config Config(cr) Display system configuration
DefaultCam DefaultCam [9](cr) Set default camera (1-7)
DspCams DspCams(cr) Display cameras connected(and Port)
Focus Focus Up/Dn/Auto/Manual,[9] (cr) Focus Up/Dn/Auto/Manual, Value
Home Home(cr) Home Camera
InCtlA InCtlA [9] (cr) Control A Bus buttons
InCtlB InCtlB [9] (cr) Control B Bus buttons
Iris Iris Up/Dn/Auto/Manual,[9] (cr) Iris change Up/Dn/Auto/Manual, Value
JPanDir JPanDir [9],[9](cr) Set Pan Direction by Port(0,1-7), Dir(Normal/Invert)
JPanSpd JPanSpeed [9],[9](cr) Set Pan Speed by Port (0,1-7), Speed(1-24)
JTiltDir JTiltDir [9],[9](cr) Set Tilt Direction by Port(0,1-7), Dir(Normal/Invert)
JTiltSpd JTiltSpeed [9],[9](cr) Set Tilt Speed by Port(0,1-7), Speed(1-20)
JZoomDir JZoomDir [9],[9](cr) Set Zoom Direction by Port(0,1-7), Dir(Normal/Invert)
JZoomSpd JZoomSpeed [9],[9](cr) Set Zoom Speed by Port(0,1-7), Speed(0-7)
Move Move(Up/Down/Left/Right/Stop)(cr) Move camera
OnCamInit OnCamInit Home/Preset12(cr) Set initialization preset Home camera or content of preset12
PanSpeed PanSpeed [9](cr) Set Preset Pan Speed
Power Power On/Off(cr) Power system On/Off
Preset Preset [9] (cr) Recalling a stored preset
PresetLoc PresetLoc[Local/InCam] (cr) Set Preset location 6 in cam 8 in system, All in system
Rescan Rescan(cr) Initiate Camera scan
Reset Reset(cr) Soft System reset
SerialEcho SerialEcho On/Off(cr) Serial Echo On/Off
SerialInfo SerialInfo(On/Off)(cr) Serial Information mode on/off
SetDefault SetDefault [9](cr) Set default Preset (1-12)
Store Store [9](cr) Store indicated preset on the current camera(1-12)
Tally Tally High/Low(cr) Non-selected(Idle) tally level
TiltSpeed TiltSpeed [9](cr) Set Preset Tilt Speed
Version Version(cr) Display System Version information
Zoom Zoom (in/Out/Stop)(cr) Zoom Camera
ZoomSpeed Set Preset Zoom Speed
GENERAL SPECIFICATIONS:
NOTE: Specifications and pricing are subject to change without prior notice or obligation.
ProductionVIEW Precision Camera Controller
Part Numbers:
999-5700-000 (North America)
999-5700-001 (International)
System I/O:
Seven (7) RS-232 Camera Control Ports on RJ-45 Connectors
Two (2) Link Ports (In and Out) on RJ-45
One (1) RS-232 Control Port on DB-9F
Seven (7) Tally Outputs - Group A, Seven (7) Tally Outputs - Group B
One (1) Power Connector (Coaxial, Positive Center, 5.5mm OD x 2.5mm ID)
Compatible Cameras:
All Vaddio HD Series Cameras, Vaddio WallVIEW Packages, Model, REVEAL & CeilingVIEW
Packages, Panasonic AW-HE100, AW-HE120 PTZ Camera, Sony EVI and BRC Series PTZ
Cameras, Canon BU Series Cameras and XU Series Cameras
Joystick:
3-Axis, Hall-Effect, Non-contacting Type with Single Button
Internally Stored Presets:
98 (14 per PTZ camera attached)
Camera Control Parameters:
Iris, Gain, Detail, Red Gain, Blue Gain, Focus (for compatible cameras)
Pan, Tilt and Zoom on Joystick
Pan, Tilt and Zoom speed (for Joystick PTZ functions)
Auto Iris, Backlight Compensation, One-Push White Balance, Auto White Balance, Fast Focus and
Auto Focus on buttons.
Note: not all functions are compatible with all cameras
LCD Display:
8-line backlit LCD display
Power Requirements:
18 VDC, 2.78 Amp Switching Power Supply
Weight:
5 lbs. (2.27kg) – approximate weight
Dimensions (H x W x D):
3.75” (95.25mm) H x 16” (406.4mm) W x 7” (177.8mm) D
