Hydraulic wing folding Tempo F
If the pins are tight: press the button for 3
seconds and adjust with the hydraulic lever to
release the pressure on the pin.
5.
Rotate the wing section by hand into the
transportation position.
- If the machine is equipped with hydraulic wing
folding, rotate the wings to the transportation
position using the hydraulic lever for wing folding.
6. Lock the wings in the retracted position with the
locking pins in position (A) on both sides.
7.
Fit both the safety catches in position (C) on both
wheel cylinders in the centre section.
The machine must not rest on the safety catches
during transportation.
44 903075-en-gb; 07.06.2017
