VADI VH-2000 - Page 6

0
1
2
3
4
5
6
7
8
9
stand by
45℃ 48℃ 52℃ 56℃ 60℃ 64℃ 68℃ 71℃ 75℃
Power Level
Heater plate
Temperature(℃)
Flow rate range
(LPM)
Temperature at
patient Y(℃)
3
5
8
52
60
71
5~40
5~40
5~40
26~30
30~34
33~36
-4-
Heater control: settings from 0 to 9. Power Level settings:
Max. Flow : 40 LPM
Max. Delievered Gas Temp. : 37.9℃ @15LPM
(Power Level : 9, room temperature 23℃± 2℃, 120cm-silicone circuit)
Performance : Temperature difference between heater plate and
patient’s side (room temperature 23℃± 2℃, silicone circuit length
22mmID / 120cm, VADI chamber G-314004):
Temperature accuracy:±3℃。
Over-heated protection:
if the heater temperature exceeds 95±6℃, the power to the
heated plate is discontinued and the Power-on/off will not be
operative.
Low Temperature Alarm:
30 min after operation, the temperature of the heater plate is 5℃
lower than setting. The display will be shown “0” and emit an alarm.
High Temperature Alarm:
While the temperature of heater plate is over 85±3℃, the display will
be shown “0” and emit an alarm.
