VADI VH-2000 - Installation

5. Installation
5.1 Slide the device on
the bracket .
(Fig.1)
5.2 Slide chamber onto
the heater base.
(Fig.2)
Note
-Choose the appropriate chamber.
5.3 Add distilled water into
chamber.(Fig.3) or stab distilled
water with the needle of IV-SET
and connect the tube to
humidification chamber.(Fig.4)
(Fig.1)
(Fig.3)
(Fig.2)
-7-
(Fig.4)
