Gas supply adjustments (Commissioning Part II) 7
Instructions for Installation and Servicing turboMAX plus and thermoCOMPACT R1 31
Burner Pressure and gas rate
Burner Pressure thermoCOMPACT 615/2 E
Output[kW]
Gas type Ignition rate 6.5 8.0 10.0 12.0 14.0 15.0
Natural gas 2H Burner pressure
1)
[mbar]
Main burner jet mark
2)
for G20
2.2 2.2 3.2 4.7 6.6 8.7 9.9
7 / 120
LPG 3 B/P
Burner pressure
1)
[mbar]
Main burner jet mark
2)
for G30 4.1 4.1 6.2 9.6 13.6 18.1 20.6
7 / 072 for G31 5.8 5.8 8.7 13.3 18.7 24.9 28.3
Burner Pressure thermoCOMPACT 620/2 E Output[kW]
Gas type Ignition rate 7.7 8.0 10.0 12.0 14.0 16.0 18.0 20.0
Natural gas 2H Burner pressure
1)
[mbar]
Main burner jet mark
2)
for G20
1.5 1.5 1.6 2.4 3.4 4.6 5.9 7.4 9.0
7 / 120
LPG 3 B/P
Burner pressure
1)
[mbar]
Main burner jet mark
2)
for G30 2.0 2.0 3.2 5.0 7.3 9.9 12.8 16.1 19.7
7 / 072 for G31 4.3 4.3 4.5 71 10.1 13.7 17.6 22.0 26.9
Burner Pressure thermoCOMPACT 624/2 E, turboMAX plus 824/2 E Output[kW]
Gas type Ignition rate 8.9 10.0 12.0 14.0 16.0 18.0 20.0 22.0 24.0
Natural gas 2H Burner pressure
1)
[mbar]
Main burner jet mark
2)
for G20
1.9 1.9 2.1 2.9 3.7 4.7 5.86.7 8.49.8
7 / 120
LPG 3 B/P
Burner pressure
1)
[mbar]
Main burner jet mark
2)
for G30 3.9 3.9 4.8 6.8 9.0 11.6 14.3 17.4 20.6 24.1
7 / 072 for G31 5.2 5.2 6.4 8.8 11.6 14.8 18.3 22.1 26.2 30.6
Burner Pressure thermoCOMPACT 628/2 E, turboMAX plus 828/2 E Output[kW]
Gas type Ignition rate 10.4 12.0 14.0 16.0 18.0 20.0 22.0 24.0 26.0 28.0
Natural gas 2H Burner pressure
1)
[mbar]
Main burner jet mark
2)
for G20
1.8 1.8 2.3 3.0 3.9 4.8 5.8 6.8 8.0 9.2 10.5
7 / 120
LPG 3 B/P
Burner pressure
1)
[mbar]
Main burner jet mark
2)
for G30 4.1 4.1 5.3 7.1 9.0 11.2 13.5 16.1 18.8 21.7 24.8
7 / 072 for G31 5.5 5.5 7.1 9.5 12.1 15.0 18.1 21.6 25.2 29.1 33.2
Table 7.1: Burner pressure
1) 15 °C, 1013mbar, dry
2) The nozzles are stamped with the mark shown in this table. The
marking corresponds to the nozzle hole diameter multiplied by 100
