Set-up
Operating and installation instructions 0020248967_00
29
5
> Use the enclosed screw and nut to
secure the adapter.
Conditions: Danfoss RAV radiator valve
A
B
3
12
> Before the installation, mount the tap-
pet extension (2) onto the valve pin.
> During the installation, ensure that the
pins inside the adapter (3) are congru-
ent to the recesses (1) on the valve.
