Set-up
30
Operating and installation instructions 0020248967_00
5
> Snap the adapter that is suitable for the
valve fully into place.
> Use the enclosed screw and nut to
secure the adapter.
Conditions: Danfoss RAVL radiator valve
2
1
> During the installation, ensure that the
pins inside the adapter (2) are congru-
ent to the recesses (1) on the valve.
