8 9
FR FR
Aperçu de l’appareil Aperçu de l’appareil
A A
8 9
EN EN
Overview of the appliance Overview of the appliance
A A
A
Set the refrigerator vertically. Open the doors to remove all the shelves (to avoid damaging
them), then close the doors.
Remove the door shelf
B
Use a spatula or a thin, flat screwdriver to prise off the screw hole cover on the top left
corner of the refrigerator and the right hinge cover on the top right corner of the refrigerator.
C
Unscrew the self-tapping collar screws used to secure the top right hinge using an 8mm
socket spanner or screwdriver (while doing so, please hold the top door with your other
hand).
D
Remove the upper hinge pin, transfer it in the opposite direction and tighten it firmly before
storing it in a safe place.
E
Remove the top door from the centre hinge by carefully lifting the door vertically.
PLEASE NOTE
When removing the door, pay attention to the washers
between the centre hinge and the bottom of the freezer
door: they may remain attached to the door. Do not lose
them.
F
Place the top door on a smooth surface with the outer panel facing up. Loosen the screw
2
and the stopper
1
and install them on the left side, tightening them firmly.
G
Unscrew the two self-tapping collar screws used to secure the centre hinge and remove
the centre hinge that holds the bottom door in place.
H
Place the bottom door on a smooth surface; with the outer panel facing up. Loosen the
screw
2
and the stopper
1
and install them on the left side, tightening them firmly.
I
Remove the screw hole covers on the left of the centre cover plate and place them on the
right (as shown below).
J
Place the refrigerator on some soft foam packing or similar material. Remove both the
adjustable foot and the bottom hinge by unscrewing the self-tapping collar screws.
K
Install the bottom hinge on the left side, securing it with self-tapping collar screws. Install
the adjustable foot on the other side and secure it.
L
Transfer the bottom door to the appropriate position, place the bottom hinge, insert the
hinge pin into the bottom hole of the refrigerator door and tighten the bolts.
Inverting the door
If necessary, the direction of the door opening can be reversed from the right (as supplied)
to the left.
WARNING
When reversing the door, the appliance must be
unplugged. Make sure the power plug is pulled out of
the socket.
Tools you will need
Not included
Socket spanner
8 mm
Thin flat-head
screwdriver
Spatula
Cross-point
screwdriver
Monkey
spanner
Spanner 8 mm
Additional part
(in the plastic pouch)
Left hinge cover
PLEASE NOTE
If necessary, the refrigerator can be placed on its rear
side for better access to the base.
To avoid damage to the rear wall, we recommend that
you rest the appliance on soft foam packaging or similar
material. To reverse the door, the following steps are
generally recommended.
