10 FR
Using the appliance
B
A
B
Rear of the dishwasher
Water supply
Drain hose
Power Cord
Drain hose
Counter
top
MAX. 1,000 mm
φ 40 mm
Draining excess water from the hoses
• If the sink is more than 1000 mm above the oor, excess water from the pipes cannot
be drained directly into the sink. It will be necessary to empty it into a suitable bucket or
container, placed outside the appliance and lower than the sink.
Water outow
• Connect the drain hose. Make sure it is securely fastened to prevent water leakage.
• Make sure the drain hose is not twisted or crushed.
Hose extension
• If you need a drain hose extension, make sure you use a similar drain hose.
• It should not be longer than 4 metres, otherwise, the cleaning performance of your
dishwasher may be reduced.
Connecting the siphon
• The wastewater connection must be within 100 cm (maximum) from the bottom of the tank.
• The water drain hose must be attached.
