Using the appliance
B
Dishwasher
Door of the
dishwasher
Cabinet
Minimum
clearance of
50 mm
NOTE : Depending on the location of your electrical outlet, it may be necessary to make
an opening in the opposite side of the cabinet.
Step 2: Dimensions and installation of the decorative panel
NOTE : The decorative wooden panel must be mounted according to the installation
diagrams.
• All-recessed model
Install the hook on the decorative wooden panel and insert it into the slot in the outer
dishwasher door (see figure
A
). After positioning the panel, attach it to the outer door with
screws and bolts (see figure
B
).
