16
B
Adjustment of the feet
The appliance must be installed on a solid and level floor surface (if necessry use a spirit level).
If the appliance is to be installed on a wooden floor, distribute the weight by placing it on a
60x60cm sheet of plywood at least 3cm in thickness and secure it to the floor. If the floor is
uneven, adjust the 4 leveling feet as required; do not insert pieces of wood etc. under the feet.
5
Slacken the locknut clockwise (see arrow) using the wrench.
6
Lift the machine slightly and adjust the height of the foot by revolving it.
Higher
Lower
7
IMPORTANT
Tighten the locknut by turning it anti-clockwise towards
the appliance casing.
max 20 mm
Using the appliance
EN
17
B
Install bottom cover
To realize quieter operation, a bottom cover is supplied with the unit (only applies to some
of the washers). After installing the cover at the bottom of the washer, the noise level will be
greatly reduced. Please ask for advice from specialists before installing the cover, nevertheless,
the machine can be used without the bottom cover.
8
Noise-Reduction Bottom Plate Installation Instructions
A:
Stick acoustic wool to the side of bottom cover plate with the letter of «PUMP».
Tilt the washer by 30»-40°, when installing the bottom cover, please face the side with sound
insulation upwards and attach ‘PUMP at the corner of the cover to the position of the pump
in the washer.
1
2
PUMP
PUMP
B:
1
Right-angle impression
Before installing the noise-reduction bottom plate, align and paste the acoustic absorption
wool with and along the right-angle impression on bottom plate (this procedure is unnecessary
for some of the models without acoustic absorption wool).
Double sided tape
2
Remove surface paper on double sided tape at four sides of the bottom plate.
Using the appliance
EN
