Valcom V-2001 User Manual

3
-
Time clock tone - single tone
- Night ring - interrupted warble tone
- Priority sequence of tones:
Page will override music;
Night ring mixes with music and with page;
Time clock overrides page but mixes with music
Capacity
- The V-2001 is a one zone single talkpath unit
with override input.
- Each V-2001 will drive up to 150 Valcom One-
Way amplified speaker assemblies (audio per
output) and provides 20 Valcom power units (1
amp of -24 VDC) for the amplified speaker
assemblies. (The V-2001 could also be used to
access 25 or 70 volt conventional amplifiers).
Dimensions & Weight
- 7.06"H x 9.0"W x 2.4"D)
(17.93 cm X 22.86 cm X 6.12 cm)
Weight: 5.0 lbs (2.27 kg.)
Nominal Specifications
Input Impedance: 600 ohms
Input Level: -10dbm nominal
Voice Switch Sensitivity: -21dbm
Music Input Impedance: 8 to 600 ohms
Music Input Level: -10dbm nominal
Output Impedance: 8 ohms
Output Level: -10dbm nominal
DC Output: -24VDC at 1 amp
Nominal Power Requirements
- Voltage: 120 VAC
- Current: 1 Amp
- Watts: 120 watts max. at peak power
NOTE: The V-2001 is equipped with a standard 3-
prong polarized MOLEX connector to allow the main
unit and a limited number of speakers to work with a
fused output (3 amp) battery backup supply (Valcom
VPB-260 or equivalent) in case of AC power failure.
Environment
Temperature: 0 to 40 Degrees C
Humidity: 0-85% non-precipitating
SYSTEM DESIGN
General
The Valcom V-2001 Integrated Single Zone (Plus)
Page Control Unit provides access to paging from a
standard PABX loop start trunk port, an Electronic
Key System C. O. line button, or a 1A2 Key system C.
O. line button (a 400 type line card is required). In
most cases, access is also possible from a PABX or
Electronic Key System page port.
Electronic Key or PABX Access
When using the V-2001 with an electronic key system
or PABX, the following equipment will be required:
1) 1 - V-2001 Integrated Single Zone (Plus) Page
Control Unit.
2) 1 - C. O. Line Circuit (Electronic key system) or
1 Loop Start Trunk Circuit (PABX)
3) Valcom One-Way Amplified Speaker
Assemblies (quantity and style determined
by specific installation).
Operation: Press the appropriate line key (electronic
key system) or dial the appropriate trunk access code
(PABX). You will immediately be connected to the
paging speakers. Make announcement. The V-2001
automatically disconnects when you hang up.
Page Port Access
When accessing the V-2001 from a telephone system
page port, the following equipment will be required:
1) 1 - V-2001 Integrated Single Zone (Plus) Page
Control Unit
2) Telephone system page card (if required for
external page outputs)
