4. Hardware
4.1 Features
Following Technologies and wireless protocols are implemented:
Name
Short description
GSM/GPRS/EDGE Rel. 9
Multi slot class 33
WCDMA/HSPA+ Rel. 9
up to HSDPA CAT 24 (42,2 Mbit/s) depending on variant
HSUPA CAT 6 (5.76 Mbit/s)
LTE Rel. 11
LTE-FDD and LTE-TDD, DL Cat 11
GNSS
GPS, Galileo, Glonass, BeiDou, SBAS, QZSS
RAT
Max transmitter power
Modulation (TX)
GSM850, 900
Class 4 (2W)
GMSK
GSM1800, 1900
Class 1 (1W)
GMSK
EDGE850, EDGE900
Class E2 (0.5W)
8-PSK
EDGE1800, EDGE1900
Class E2 (0.4W)
8-PSK
WCDMA Rel.99, HSPA+
Class 3 (0.25W)
QPSK, 16-QAM, 64-QAM,
BPSK
LTE
Class 3 (0.25W)
QPSK, 16-QAM, 64-QAM,
