If the problem persists, please follow
these steps:
1. Contact the dealer where you purchased
the product�
Replace the product ECU and recheck 2.
the system�
Test camera with certied ECU.3.
Plug certied camera into the ECU and 4.
recheck�
There is no image on the display:
Is the power supply wire connected correctly?1.
Is the ignition turned to ACC ON?2.
Is the reverse gear selected?3.
Are all wire connections correct?4.
Check the correct function setting of the display�5.
Image on the display without selecting the reverse gear:
Check whether the power wire of ECU is connected to the
reverse light wire�
Blurred image or poor quality image on the display:
1. Check whether there is dirt or water on the lens of the
camera�
Clean the lens with a lint with alcohol, and then dry it with 2.
a clean cloth�
Is there enough power supply provided to the ECU?3.
Troubleshooting
