VALKYRIE Vind SL125 - Page 18

12
AMD AM4/AM5 Installation
We have marked the parts required for installing the AMD/AM4 platform for you.
2x AMD Brackets 4x Intel/AMD Bolts
1x Nut Socket 1x Extension Cord
4x Nuts
4x Fan Cable Clips
Step 1: Prepare the motherboard
Screw out the 4 bolts. Remove the original bracket on the motherboard. Keep
the original backplate.
2x Fan
SL125
1x Forward Curved Fan
1x Backward Curved Fan
DL125
2x Forward Curved Fan
EN
