Pressing the ‘LAMP’ button.
This turns the effect on. The indicator lamp (See figure 24) will flash
green for approximately five seconds, after this time the lamp will no longer be visible.
An internal fan is used to produce the flickering flame effect, room temperature air will
be felt coming from the outlet at the top of the firefront. The heater does not produce
cold air.
Pressing the ‘Heat 1’ button.
This turns the effect and 675 watt heater on. The indicator lamp will
flash amber for approximately five seconds, after this time the lamp will no longer be
visible.
Pressing the ‘Heat 2’ button.
This turns the effect and 1350 watt heater on. The indicator lamp will
flash red for approximately five seconds, after this time the lamp will no longer be
visible.
Pressing the red ‘ON/OFF’ button.
Pressing this button at any time whilst the
effect and heater are in operation
will turn the effect and heater off.
Manual Control - What is it and why is it
there?
The manual control is there as a back up. If the
remote control has been damaged, lost, or the
batteries lives have expired, the manual control will
enable the effect and heater to be
operated.
The control is located behind the ash pan cover on
the lower right hand side of the heater (See figure
25).
Figure 24. lamp locations
Figure 25 (Shown without
firefront and ash pan - Fascia
may differ from that shown)
