GEN2-V1 12ft-Instructions (Severe Weather) doc:r1
5. RETRACTABLE AWNING SCHEMATIC DRAWING
Size: 10-ft Projection X 12-ft. Width
Diagram: Exploded View
12 LEFT BRACKET ASSEMBLY
13 RIGHT BRACKET ASSEMBLY
GEAR MECH. & ROLLER
TUBE SUPPORT BRACKET
ROLLER TUBE SUPPORT &
PLASTIC BUSHING
13
WRIST ASSEMBLY
POSITION POLE
LEVEL
