Valore VS 2000 Plus - Page 11

Diverter Valve Structure
How to Remove the Diverter Valve
• Remove the cover(#3) to open the set screw access hole.
1
• Loosen the set screw (#1) from the valve stem and pull
the knob (#2) straight out.
2
(2.5 mm)
3
2
1
• Loosen and remove the gland nut (#4).
4
4
3
4
5
Diverter valve
3
1
• Remove the Diverter valve (#5) by pulling it straight out.
5
Diverter valve
4
(2.5 mm)
2
1
1
- 11 -
