1. Turn the Switch to position "1".
2. Correctly and firmly connect the hoses.(See Connection Drawing).
3. Turn the power on, turn the BYPASS switch to MANUAL and hit the start button.
4. Open the gas valve and liquid valve of the refrigerant tank.
5. Turn the Switch to position " 2" to start fast liquid recovery.
HVAC Syetem
O.F.P. cable
Scale
Tank
Vapor
Liquid
Input
Output
Filter
Liquid valve
Vapor valve
8 9
After each use the unit must be purged, make sure there is no refrigerant left in the
unit. Liquid refrigerant remained may expand and damage the components.
