ValueHD VHD-V500N - Page 27

ValueHD Corporation
26
y0 50 03 FF
Off
CAM_RegisterValueI
nq
8x 09 04 24 mm FF
y0 50 0p 0p ff
mm: Register No. (00 to FF) pp: Register
Value (00 to FF)
CAM_ColorGainInq
8x 09 04 49 FF
y0 50 00 00 00 0p FF
p: Color Gain setting 0h (60%) to Eh
(200%)
CAM_IDInq
8x 09 04 22 FF
y0 50 0p 0q 0r 0s FF
pqrs: Camera ID
CAM_VersionInq
8x 09 00 02 FF
y0 50 ab cd
mn pq rs tu vw FF
ab: Factory Code(00: VHD, 01:MR,
08:T)
cd: Hardware Version
mnpq: ARM Version
rstu: FPGA Version
vw: Camera model
01: C Type
02: M Type
03: S Type
VideoSystemInq
8x 09 06 23 FF
y0 50 00 FF
1920x1080i60
y0 50 01 FF
1920x1080p30
y0 50 02 FF
1280x720p60
y0 50 04 FF
NTSC
y0 50 05 FF
NTSC
y0 50 06 FF
NTSC
y0 50 07 FF
1920x1080p60
y0 50 08 FF
1920x1080i50
y0 50 09 FF
1920x1080p25
y0 50 0A FF
1280x720p50
y0 50 0C FF
PAL
y0 50 0D FF
PAL
y0 50 0E FF
PAL
IR_Receive
8x 09 06 08 FF
y0 50 02 FF
On
