Plug-in modules

Number Description

1 Wireless receiver slot

2 Primary modem slot

3 Back-up modem slot

For installation details, see the corresponding Installation Instruction.

Installation guides are available at http://www.spcsupportinfo.com/connectspcdata/userdata.

SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Wiring the system

11.2018
