What does peripheral protection mean on a V&T Inverter?
If your V&T Inverter indicates peripheral protection, check: * **External failure terminal enabled:** Check the external failure terminal status. * **Stall over voltage or over current lasting more than one minute:** Check whether the external load is normal.
What to do if V&T V5 Inverter has over current protection during deceleration?
If your V&T Inverter displays an over current protection error during deceleration, consider the following: * **Low grid voltage:** Check the input power supply. * **Large rotating inertia of load:** Choose an appropriate dynamic braking unit and braking resistor. * **Improper motor parameters:** Ensure motor parameters are set correctly. * **Short deceleration time:** Prolong the deceleration time. * **Inadequate inverter power level:** Replace the inverter with a model that is more suitable.
Why is my V&T V5 Inverter showing an overload protection?
An inverter overload protection error in your V&T Inverter can occur due to several reasons: * **Input power undervoltage:** Check the input power supply. * **Fast start-up with a high-speed motor:** Restart after the motor stops rotating. * **Prolonged overloading:** Shorten the overloading time and reduce the load. * **Short acceleration/deceleration time:** Prolong the acceleration or deceleration time. * **High V/F curve ratio:** Adjust the V/F curve setting and torque boost. * **Inadequate inverter power level:** Replace the inverter with a model that is more suitable.
V&T V5 Inverter: How to resolve over current protection during constant speed operation?
If your V&T Inverter shows an over current protection error during constant speed operation, check these: * **Sudden load changes:** Decrease the load’s abrupt frequency change and amplitude. * **Improper motor parameters:** Ensure motor parameters are set correctly. * **Inadequate inverter power level:** Replace the inverter with a model that is more suitable.
What to do if V&T V5 shows copy failure?
If your V&T Inverter displays a copy failure message, check: * **Data error when uploading:** Check the connection of the operation panel. * **Data error when downloading:** Check the connection of the operation panel. * **Parametric copy download without parameter upload:** Perform download before uploading the parameters. * **Software version incompatible:** Check if d1.09 is consistent.
What does hardware overload protection mean for V&T Inverter?
If your V&T Inverter indicates hardware overload protection, check whether the motor is blocked and consider replacing the inverter with a proper model if necessary.
What does analog input abnormal mean on my V&T Inverter?
If your V&T Inverter is showing an analog input abnormal error, check: * **Analog input voltage is too large:** Check whether the analog input voltage complies with the requirements. * **Analog input circuit failure:** Seek for technical support. * **Analog input circuit signal interfered:** Increase the P6.22?P6.24 AI filtering time.
What does interference protection mean for V&T V5 Inverter?
If your V&T Inverter is severely interfered with by an exterior signal, ask professional technicians to maintain it.
How do I fix heatsink 1 over temperature protection on my V&T V5?
If your V&T Inverter displays a heatsink 1 over temperature protection error, check: * **Ambient over-temperature:** Lower the ambient temperature and strengthen ventilation and heat dissipation. * **Blockage of air duct:** Clean the dust, wool, and other foreign objects in the air duct. * **Fan failure:** Check if the fan power cable and fan are normal. * **Inverter module failure:** Seek for technical support. * **Temperature detection circuit failure:** Seek for technical support.
What does module protection mean on my V&T V5?
Module protection on your V&T Inverter can be triggered by: * **Output over current:** Check whether the motor and the output connection are short circuited, whether the ground is short circuited, and whether the load is too heavy. * **DC terminal overvoltage:** Check the mains power supply and whether the large inertia load has no function of quick stop at energy consumption brake. * **Loose connection of connectors inside the inverter:** Ask professional technicians to maintain.
Combines PLC and high-performance vector inverter for crane applications.
Achieves 180% rated torque at low frequencies with fast response.
Prevents slip hook phenomenon during brake opening and closing.
Ensures stable acceleration and deceleration with reliable brake control.
Offers 1.2 times overload capacity for heavy-duty crane applications.
Automatically calculates load for maximum speed and safety.
Enables precise positioning and intelligent deceleration using PG feedback.
Supports standard bus communication protocols for flexible integration.
Allows safe operation via keyboard during system failures.
Provides extensive monitoring and protection functions for reliable operation.
Details inverter features suitable for port and portal crane applications.
Explains inverter suitability for tower cranes and lifting mechanisms.
Covers inverter use in electric hoists and overhead crane systems.
Discusses inverter application in mine hoists and winch operations.
Focuses on inverter features for precise grab bucket control.
Explains the meaning of digits and letters in the inverter model field.
Details the information provided on the inverter's nameplate.
Lists the different product series and their specifications.
Provides physical dimensions and weight for various inverter models.
Guides on selecting appropriate brake resistors for different inverter models.
Illustrates connection diagrams for power supply, motors, and peripherals.
Describes the functions of terminals in the main circuit of the inverter.
Details wiring for digital, analog, and communication signals.
Provides a comprehensive wiring diagram for all terminals.
Introduces the digital panel, keys, indicators, and their functions.
Explains the step-by-step procedure for changing parameters via the keypad.
Demonstrates common parameter settings and operations with examples.
Defines items like Function code, name, setting range, unit, and property.
Lists parameters for user password, protection, and display modes.
Covers parameters for acceleration, deceleration times, and torque compensation.
Details parameters for key lock, multi-function key definition, and display settings.
Includes parameters for startup mode, DC braking, and stop modes.
Defines multi-step frequency references and associated acceleration/deceleration settings.
Lists parameters for configuring digital inputs and terminal functions.
Covers parameters for analog input channels and curve corrections.
Details parameters for terminal outputs and their functions.
Parameters for overspeed, stall, and zero current detection levels.
Essential parameters for motor identification and tuning.
Parameters for carrier frequency, current limit, and voltage adjustment.
Parameters for hopping frequency and automatic restart functions.
Settings for communication baud rate, data format, and local address.
Advanced parameters for vector control, speed, and torque loops.
Stores fault history, including type, voltage, current, and frequency.
Parameters related to brake control, hysteresis, and feedback.
Configuration for terminal-based frequency increment/decrement control.
Settings for position calculation, automatic stop, and related parameters.
Details the function of the EX-DT01 expansion card.
Steps to verify that all wiring connections are firm and correct.
Procedure for auto-tuning the motor parameters without load.
Settings required for closed-loop vector control using encoder feedback.
Configuration of acceleration, deceleration, and control modes for startup.
Setting the mode for speed reference input (terminal or communication).
How to set parameters for controlling the brake signal output.
Specific debugging steps for conical motors with built-in brakes.
Detailed method for calculating and setting position control parameters.
Instructions for copying parameters between inverters for batch setup.
Steps to run the inverter without a motor connected, avoiding alarms.
How to monitor various parameters and input terminal status during operation.
Lists fault codes, descriptions, possible causes, and countermeasures.
Analyzes common issues like low torque, overspeed, and overload.
General| Cooling Method | Forced air cooling |
|---|---|
| Protection Level | IP20 |
| Output Voltage | 0~Input voltage |
| Frequency | 50Hz/60Hz |
| Control Mode | V/F control |
| Braking Unit | Built-in or external (optional) |
| Communication | Profibus |
| Protection Features | Over-current, over-voltage, under-voltage, over-heat, overload, short circuit, phase loss |
| Storage Temperature | -20℃~+60℃ |
| Humidity | 5% to 95% (non-condensing) |
| Altitude | Lower than 1000m, derating if altitude exceeds 1000m |
