VM-5500 Operator’s Manual
2.3.2 Implement Type Select
Use the Check Boxes to select if your monitor is connected to seed sensors, flow meters or both. If you
select Flow 1, you may select Flow 2 as well if you are using two different flow rates on your
system. Keep in mind that you are limited to 16 total sensors on this monitor. Depending on your
selections the monitor will configure itself to ask for only the required parameters.
Figure 5 Implement Configuration with All Sensors
For each Flow you have set, you may selection if there is a Sensor per Row, or only Sensor at the pump
or Master Flow. This Flow selection is independent for each Flow (1/2). In the page above you would
have an Implement with Seeds and Flow 1 with sensors at each row.
Press Ok will return you to the Starter page which will now look like this.
2.3.3 Implement Row, Spacing and Width settings
For the Row, Spacing and Width settings press the appropriate button and a Numeric keypad will pop-
up. Enter your number of Rows first, if you then enter the Spacing your Width will be calculated for you.
If after the Row entry, you enter the Width the Spacing will be calculated for you. You can override the
calculated values if you desire.
Image indicates you
selected Seeds and Flow
To Next Page
