Vanguard System VM-5500 User Manual

VM-5500 Operator’s Manual
2018
Rev 0418.1 | Introduction
7
1.2 Specifications
Power
10–16 VDC, 3.5 A maximum
Operating temperature
range
-20°C to 70°C (-4°F to 158°F)
Storage temperature
range
-40°C to 85°C (-40°F to 185°F)
Size
27.30 cm W x 16.50 cm H x 5.08 cm
D (10.75" W x 6.5" H x 2" D)
Weight
3.08 kg (6.8 lbs.) for 16-row VM-5500
system
Wire Harnesses
The VM-5500 includes detachable
harnesses to supply the unit's power
(fused) and sensor inputs (to hitch).
Connectors on the back for GPS
Antenna, USB on Front, Radar on
Bottom
Sensors
Compatible with Vanguard and other
major brands of seed sensors.
Standard mounting
RAM Mount 1 ½ ” Ball Mounting
Alarm adjustment
Four levels audible alarm with mute
onscreen selection. Optional external
light available.
Backlight adjustment
Five increments plus Day/Night
mode
SAFETY NOTICES

Vanguard System VM-5500 Specifications

General

Brand	Vanguard System
Model	VM-5500
Category	Monitor
Language	English
