28
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Rated Continuous Power Output:
Center (20Hz - 20kHz 0.05% THD, 8Ω) --------------------------------------------------100W
Surround (20Hz - 20kHz 0.05% THD, 8Ω) --------------------------------------------------100W
2 channels driven (0.05% THD, 8Ω) ---------------------------------------------85W + 85W
Dual transformer design with dedicated toroid for amplifiers with thermal protection
Dynamic power per channel (4Ω/6Ω/8Ω) ----------------------------------150W/120W/100W
Frequency response --------------------------------------------------------------0 ± 0.5dB 20Hz-20kHz
Total harmonic distortion --------------------------------------------------------------0.05% 20Hz-20kHz
Signal to noise ratio (CCIR/ARM)
at speaker out(re. rated power) -----------------------------------------------------90dB
at line out (re. 2V) --------------- C/LS/RS = 92dB ----L/R/SUB = 85dB
Channel isolation ---------------------------------------------------------------------------------------->70dB
Volume control range -------------------------------------------------------------------------75dB and mute
Speaker trim range -------------------------------------------------------------------------------------20dB
Digital Decoder Modes: -----------------------------------Dolby Digital 5.1 audio, Pro Logic, MPEG,
2/4-channel Stereo, and Dolby Digital Karaoke playback
D/A converters --------------------------------------------------------------------------------20 bits, 96kHz
Sampling frequencies -----------------------------------------------------------48kHz, 44.1kHz, 32kHz
Bass crossover Frequencies ------------------------------------------------------------80Hz, 100Hz, 120Hz
Filter response ----------------------------------------------------------------------------------------12dB/oct.
Center channel delay --------------------------------------------------------------------0-5ms in 1ms step
Surround channel delay ----------------------------------------------------------------0-15ms in 1ms step
(Pro Logic automatically adds 15ms)
Master Volume Tracking Accuracy : ---------------------------------------------------------------- ± 1dB
Digital Connections (DVD/CD/LD/TV):
Coaxial (2) --------------------------------------------------------------------------------------0.5Vp-p / 75Ω
Optical (1) ----------------------------------------------------------------------------------------------TOSLINK*
Analog Connections (Audio Line Out/Line In/Tape Play In):
Input level / impedance --------------------------------------------------------------------------2V / 47kΩ
Output level / impedance ----------------------------------------------------------------------2V / 330Ω
Maximum output capability ------------------------------------------------------------------------------5.5V
Maximum subwoofer output capability ------------------------------------------------------------- 9V
Power Supply
U.S.A. and Canada models ---------------------------------------------------------------AC 120V, 60Hz
Other models -------------------------------------------------------------------------------AC 220V, 50Hz
Power consumption --------------------------------------------------------------------------250W, 316VA
Standby power consumption -----------------------------------------------------------------------------6W
Dimensions: ----------------------------------------------------------17" (W) x 4.125" (H) x 14.5" (D)
432mm (W) x 105mm (H) x 368mm (D)
Weight: --------------------------------------------------------------------------------------24 lbs., (10.9 kg)
TOSLINK is a trademark of Toshiba Corp.
SPECIFICATIONS
Specifications and features are subject to change without notice.
