DSH-M100U3 Page 10
* Actual strings depend on your Operating System. This screen
shot is from Windows 7 and may vary slightly for different
Operating Systems.
3. Connecting Ethernet network device
Connect an Ethernet cable to the RJ45 port on the USB 3.0
Universal Mini Docking Station Adapter and connect the other
end of the Ethernet cable to your network hub/switch/router
4. Connecting HDMI monitor/projector
Use a HDMI cable (not provided) to connect the HDMI port to a
monitor equipped with HDMI input jack. If your monitor do not
have a HDMI, you can use the provided HDMI to DVI adapter to
connect to your monitor.
5. Connecting USB 2.0/USB 3.0 device
Connect your USB device to the USB 3.0 port on the USB 3.0
Universal Mini Docking Station Adapter.
