CHAPTER 6 SPECIFICAITONS
1. VIDEO
Input Level 1.0 Vp-p±10% Composite, 75Ω Balanced
NTSC 480 fps(16CH), 240fps(8CH), 120fps(4CH)Display Speed
PAL 400 fps(16CH), 200fps(8CH) , 100fps(4CH)
NTSC 720(H) X 480(V)Display Resolution
PAL 720(H) X 576(V)
Monitor Output 2Vp-p Composite, 75Ω Balanced
2. RECORDING
Compression Method H.264
Recording Speed Refer to table 7-1
NTSC 720 X 480, 720 X 240, 352 X 240Recording Resolution
PAL 720 X 576, 720 X 288, 352 X 288
Quality Independent for
each channel
Lowest/ Low/ Normal/ High/ Highest
Schedule Setup by “minute” as unit
Mode Manual / Event (Motion, Sensor) / Schedule
Method By resolution, fps and quality
Setup fps and quality separately for normal and
event recording
3. SATA DEVICE
Internal Storage 3 HDDs or 2 HDDs + 1DVD-RW (16 CH)
2 HDDs or 1 HDDs + 1 DVD-RW (4CH/ 8CH)
Capacity
External Storage 1 HDD
Type
SATA / SATAⅡ compatible
External Bay Interface E-SATA
4. ALARM
Sensor Input 16(16CH), 8(8CH), 4(4CH)
Loop Out 1 Relay out
Motion Detection Available per each camera/ Multi-detection level
5. CONNECTIONS
Video Input BNC 16 ports (16CH), 8 ports (8CH), 4 ports (4CH)
Video Output BNC 2 port, VGA 1 port (Optional)
Audio Input RCA 4 CH
Audio Output RCA 1 CH
USB 2.0 USB memory stick, USB Mouse, USB Touch Panel
Remote Remote control, 1-to-8 remote control (optional)
External I/O 1 RS-485, 16(16CH) / 8(8CH) / 4(4CH) sensor input,
1 Relay Output
Ethernet 1 RJ45 connector, 10/100 Mbps
6. ELECTRICAL
Power Source DC 12V / 6.25A (16CH) ,
DC 12V / 5A (8CH) , DC 12V / 5A (4CH)
7. ENVIRONMENTAL
Operation
5℃ ~ + 40℃
