VT-MOD-CELL-B48 Hardware User Manual
6
112 GND
113 GND
114 GND
115 Reserved Reserved
116 GND
117 GND
118 Reserved
Floating
119 Reserved
Floating
120 GND
Note 1: In Table 2-1, P: power supply pin; I: digital signal input pin; O: digital signal
output pin; I/O: signal input/output.
Note 2: Reserved GPIO can be customized, such like LED indicator.
Note 3: For details about the description, functions and usage of each pin listed in
Table 2-1, please refer to the related chapters.
